Datasheet PW-567ER
Carton Erector
.The machine is durable and designed for safety and low break-down.
.Automatically open the empty carton, fold all flaps and seal the bottom. It is solid, fast and work +efficiency.
.Manual adjusted width.
.Auto adjusted height.
.Single folding.
Datasheet PW-567ER
Carton Erector
Chart of types model PW-567ER
Kemex Strapping Systems 1850, Transcanadienne, ++++.Dorval (Québec) + + . Tél: 514-685-1119 ++++. .800-755-3639 +..Fax: 514-685-2228
>> Go back to the Website
>> Retour au site
>> Go back to ++.the Website
>> Retour au site
Power Supply: +++++++++++++++++++++++++ ++. ,+1 Ø, / 110V / 220V, (50/60Hz), 4L
++++++++++++++++++++++++++++++,+++ +++++ 3 Ø, 220V,380V, 440V, (50/60Hz), 4L

Electric consumption: ++++++++++++++++++++++++++++++++1.5 KW
Case Range: +++++++++++++++++++++++,+++++L330~500 x W260~400 x H200~380mm
Other specification can be made by request.
Air: ++++++ ++++++++++++++++++++++++++++,,,,,,+++++6kgf/cm
Capacity: ++++++++++++++++++++++++++++,++,++++++++4~12 cartons/ min
.Put 30~50 empty cartons into the machine's storage.
.Automatically done with open the carton, fold all flaps and seal the bottom.
.Manual adjusted the opening carton sizes.
Workstation Introduction :
OPP width: ++++++++++++++++++++++++++++++++++++.+++ +2" or 3"
OPP length: ++++++++++++++++++++++++++++++++++,++++++1000Y
OPP thickness:++++++++++++++++++++++++++++++++++++++++,,55~70 microns
Empty carton storage: ++++++++++++++++++++++++++++++++30~50 pcs
+++++++++++++++++++++++++++++++++++++, (depends on the carton thickness)
